Black PET leader tape
PRODUCT DESCRIPTION
Black PET Leader Tape for COB Packaging
Tongxi manufactures Black PET Leader Tape for COB (Chip on Board) packaging processes requiring accurate reel guidance, consistent tape feeding and antistatic material properties. Made from DuPont PET film, our black antistatic PET leader tape is available in 35 mm, 48 mm and 70 mm widths, with a standard thickness of 0.125 mm, a 1.42 mm aperture and a 4.75 mm hole pitch.
For manufacturers replacing existing leader tapes or adapting materials to different packaging equipment, Tongxi supports customized tape thicknesses, aperture configurations, hole positions, roll lengths and surface treatments. You can supply your existing tape sample, technical drawing or equipment specifications for a compatible Black PET Leader Tape solution. For other materials and product types, explore our semiconductor packaging leader tape range.
Black PET Leader Tape Specifications
| Parameter | Standard Specification | Optional / Custom Specification |
|---|---|---|
| Product Name | Black PET Leader Tape | Custom Black Antistatic PET Leader Tape |
| Base Material | DuPont PET Film | Alternative PET film grades according to mechanical and electrical requirements |
| Color | Black | Black surface finish and treatment options according to the selected material grade |
| Film Thickness | 0.125 mm (125 μm) | 0.075 mm / 0.188 mm; |
| Tape Width | 35 / 48 / 70 mm | Custom widths according to customer drawings and processing requirements |
| Aperture Size | 1.42 mm | 1.98 mm or other custom aperture dimensions according to the required hole design |
| Hole Pitch | 4.75 mm | Custom pitch according to drawing |
| Hole Shape | According to the selected perforation configuration | Square, round or specially designed apertures according to the approved drawing |
| Hole Position | According to the selected tape model | Custom hole-center position and edge distance |
| Roll Length | 300 m/roll | 2–300 m; |
| Electrical Properties | Antistatic PET grade | Customer-specified electrical resistance and surface treatment requirements |
| Surface Finish | Black PET surface | Glossy or other specified surface finishes; |
| Processing | Precision punching and slitting | Custom perforation, cutting, |
| Primary Applications | COB and IC Packaging | Semiconductor reel-to-reel handling and equipment-specific tape feeding |
Black PET Leader Tape Size and Perforation Options
| Configuration | Available Specifications | Selection Guidance |
|---|---|---|
| 35 mm Black PET Leader Tape | 35 mm width; 0.125 mm standard thickness | Select when your packaging equipment requires a 35 mm tape format. Confirm the aperture configuration and hole position before ordering. |
| 48 mm Black PET Leader Tape | 48 mm width; standard or custom perforation | Match the tape width, sprocket engagement and perforation layout to the existing reel-to-reel transport system. |
| 70 mm Black PET Leader Tape | 70 mm width; standard or custom perforation | Confirm the tape path, hole position and winding requirements for your 70 mm equipment configuration. |
| 35SW / 48SW Configurations | Alternative perforation configurations within the corresponding tape-width families | Confirm the exact SW hole pattern against your existing leader tape or equipment drawing. The model suffix alone should not be used to determine the aperture dimensions. |
| Alternative Aperture Size | 1.98 mm; custom aperture dimensions | Specify the aperture shape and dimensions, rather than assuming the value represents a circular hole diameter. |
| Custom Perforation | Custom hole size, pitch, position and edge distance | Recommended when replacing a proprietary leader tape or adapting to a non-standard feeding mechanism. |
Perforation requirement: A 1.42 mm or 1.98 mm aperture may be defined differently depending on the hole geometry. For precision replacement orders, provide the hole shape, aperture dimensions, center-to-center pitch and distance from the tape edge. Tongxi can manufacture the specified configuration according to the approved drawing.
Equipment Compatibility and Replacement Selection
If you are replacing an existing Black PET Leader Tape, the most reliable approach is to compare its physical dimensions and operating requirements with the proposed replacement. Matching the nominal tape width is not enough to confirm interchangeability.
| Compatibility Factor | What You Need to Check | Tongxi Supply Options |
|---|---|---|
| Tape Width | Existing tape width and guide-channel clearance | 35 / 48 / 70 mm standard widths; custom slitting available |
| Film Thickness | Existing material thickness, roller clearance and tape flexibility | 0.125 mm standard; 0.075 / 0.188 mm optional PET configurations |
| Aperture Dimensions | Hole shape, size and compatibility with the feeding pins | 1.42 / 1.98 mm options; custom aperture designs |
| Hole Pitch | Center-to-center distance between successive apertures | 4.75 mm standard; custom pitch available |
| Hole Position and Edge Distance | Distance between the perforations and the tape edges | Custom hole position according to customer drawings |
| Dimensional Tolerances | Permitted variation in tape width, hole size, pitch and position | Project-specific dimensional tolerances defined in the approved specification |
| Reel Configuration | Roll length, core inside diameter, winding direction and equipment mounting | 300 m standard roll; custom roll and winding specifications |
| Electrical Requirements | Required antistatic performance, resistance measurement and operating environment | Black antistatic PET grades with project-defined electrical specifications |
| Operating Conditions | Web tension, process temperature, feeding speed and contact conditions | PET material and thickness selection according to the specified conditions |
Custom Black PET Leader Tape Manufacturing
Tongxi offers custom black PET leader tape configurations for semiconductor manufacturers, packaging material suppliers and equipment-specific applications. Customization covers PET film selection, tape dimensions, precision perforation, surface properties and reel format.
| Custom Parameter | Available Range / Options |
|---|---|
| PET Film Thickness | 0.075–0.188 mm custom thickness range, including 0.075 / 0.125 / 0.188 mm configurations |
| Tape Width | 35 / 48 / 70 mm and custom widths according to drawing |
| Aperture Size | 1.42 mm / 1.98 mm; other dimensions according to drawing |
| Hole Pitch | 4.75 mm standard; alternative pitch according to drawing |
| Hole Pattern | Square, round or custom perforation designs |
| Roll Length | 2–300 m; special lengths according to project requirements |
| Roll Configuration | Customer-specified core size and winding direction |
| Surface Finish | Black PET, glossy finish and specified surface-treated options |
| Antistatic Properties | Customer-defined electrical resistance target and suitable PET treatment |
| Mechanical Properties | PET grade selection according to tensile strength, elongation and dimensional stability requirements |
| Special Processing | Precision slitting, punching, custom cutting and special hole patterns |
PET Material and Antistatic Performance
Tongxi's standard Black PET Leader Tape uses DuPont PET film. PET provides the flexibility and mechanical strength required for reel guidance and continuous tape transport. The black version is supplied for applications requiring antistatic material characteristics.
Different packaging lines may impose different requirements for web tension, dimensional stability and electrical resistance. The following table identifies the properties that should be confirmed when selecting a standard or custom Black ESD PET Leader Tape.
| Property | Available Specification | Purchasing Consideration |
|---|---|---|
| Base Film | DuPont PET standard; alternative PET grades available | Select according to the existing tape specification and processing conditions. |
| Thickness | 0.125 mm standard; 0.075 / 0.188 mm optional | Confirm the required balance between flexibility, handling and feeding stability. |
| Antistatic Performance | Antistatic grade; custom resistance requirements | Define the required electrical resistance and measurement method for the selected grade. |
| Tensile Strength | According to the selected PET grade and specified performance requirement | Important when tape is exposed to continuous pulling tension. |
| Elongation | According to the selected PET grade | Consider elongation requirements when dimensional accuracy under tension is critical. |
| Dimensional Stability | According to material grade and operating conditions | Evaluate when the tape operates under defined tension or temperature conditions. |
| Surface Treatment | Standard black PET surface; optional treated or coated configurations | Specify any electrical, surface-contact or contamination-control requirement. |
Black PET Leader Tape Applications
| Application | Function of the Leader Tape |
|---|---|
| COB Packaging | Supports reel guidance and tape feeding during COB packaging operations. |
| IC Chip Packaging | Provides a precisely perforated leader section for compatible tape-transport processes. |
| Semiconductor Reel-to-Reel Handling | Assists tape threading, transport and controlled feeding through compatible equipment. |
| Replacement Leader Tape Supply | Provides an alternative material configuration matched to an existing tape design. |
Black PET vs. White PET Leader Tape
Tongxi supplies both black and white PET leader tapes. The most suitable version depends on your existing material specification, color requirements and electrical performance requirements.
| Comparison | Black PET Leader Tape | White PET Leader Tape |
|---|---|---|
| Material | PET Film | PET Film |
| Color | Black | White |
| Available Widths | 35 / 48 / 70 mm | 35 / 48 / 70 mm |
| Aperture Options | 1.42 / 1.98 mm and custom | 1.42 / 1.98 mm and custom |
| Antistatic Properties | Antistatic characteristics identified in the product specifications | Depends on the selected white PET grade |
| Main Selection Basis | Black PET requirements, antistatic specification and equipment compatibility | White PET requirements, material specification and equipment compatibility |
If your process requires a white PET configuration, see our White PET Leader Tape. Color alone should not be used to determine electrical performance or direct interchangeability.
Quality Documentation and Sample Evaluation
Zhuhai Tongxi Electronics Technology Co., Ltd. manufactures and supplies materials for IC, semiconductor and smart card packaging. Tongxi reports an ISO 9001 quality management system and publishes RoHS and halogen test reports relating to leader tape products. The applicable report and its coverage should be checked against the selected material, color, thickness and custom configuration.
Tongxi's leader tape product range also includes standard-model sample support and batch Certificate of Conformity (CoC) and dimensional inspection documentation. Standard 35/48/70 mm model samples are described as available with same-week dispatch. Custom sample requirements and production delivery arrangements should be confirmed separately.
For replacement or custom leader tape projects, we recommend evaluating the selected tape against your approved drawing and packaging equipment before proceeding with volume purchasing. You can review Tongxi's published company information and available reports on our company and certification page.
Black PET Leader Tape FAQ
Can Tongxi manufacture Black PET Leader Tape to match our existing product?
Yes. Tongxi supports custom width, thickness, aperture size, hole pitch, hole position and reel configurations. Send your existing product drawing or sample, including any critical dimensions and tolerances. We can review the required configuration for replacement supply.
Are 35 mm, 48 mm and 70 mm Black PET Leader Tapes interchangeable?
No. These are different width configurations. Even tapes with the same width may have different perforation patterns or hole positions. Confirm the aperture design, pitch, edge distance and reel specifications against your packaging equipment before selecting a replacement.
Can we order Black PET Leader Tape with 1.98 mm apertures?
Yes. In addition to the published 1.42 mm configuration, Tongxi offers 1.98 mm apertures and custom perforation dimensions. Please provide the required hole shape, dimensions, pitch and position so that the correct punching configuration can be specified.
Can you supply thicknesses other than 0.125 mm?
Yes. The standard Black PET Leader Tape thickness is 0.125 mm. Additional PET configurations, including 0.075 mm and 0.188 mm, are available as optional specifications. Other thickness requirements within the 0.075–0.188 mm custom range can be reviewed according to the selected PET grade and processing requirements.
Does every Black PET Leader Tape have the same antistatic performance?
Not necessarily. The electrical properties depend on the PET grade and surface configuration. If your packaging process requires a defined resistance value, provide the target, measurement method and applicable requirements. The selected configuration and available technical documentation should be confirmed before ordering.
Can you provide short rolls for equipment trials?
The published standard roll length is 300 m. Alternative lengths within 2–300 m are available for custom configurations. Tongxi also offers sample support for standard leader tape models. Please specify the required trial length, tape width and perforation pattern when requesting a sample or quotation.
What information should we provide for an accurate quotation?
Please provide your required PET thickness, tape width, aperture size and shape, hole pitch, hole position, roll length and order quantity. If the tape must match an existing machine, include the equipment model, reference drawing or existing tape sample. Specify any electrical, mechanical, dimensional or documentation requirements that are critical to acceptance. MOQ and production lead time are determined according to the selected configuration and order requirements.
Request a Quote for Black PET Leader Tape
Need a reliable supply of Black PET Leader Tape for COB packaging? Send Tongxi your standard specifications or custom drawing, including tape width, thickness, aperture dimensions, hole pitch, roll configuration and estimated purchase quantity. Our team can review the required PET grade, perforation design and manufacturing options to help you select a compatible product for your packaging process.
Whether you need standard 0.125 mm Black PET Leader Tape or a custom precision-punched configuration, contact us to discuss technical requirements, sample options, order quantities and pricing.Contact Tongxi for Black PET Leader Tape Specifications and a Quote.
