Wafer gasket: The antistatic Guard of semiconductor manufacturing
Feb. 18, 2025
In the semiconductor manufacturing process, wafers need to go through hundreds of processes. Any small electrostatic discharge may cause fatal damage to the wafers, resulting in a decrease in product yield and huge economic losses. Wafer pad as the key interface material between wafers and equipment, assume the important mission of antistatic, cushioning and protection.
“Triple protection” of wafer gaskets-optimized and upgraded
Excellent antistatic performance: Using advanced polymer composite materials, the surface resistivity can be accurately adjusted between 10^3-10^11 Ω/Square to meet the needs of different electrostatic protection levels, effectively prevent static accumulation and discharge, and provide a full range of electrostatic protection for wafers.
Excellent cushioning and shock absorption performance: Optimize the material formula and structural design to give the wafer gasket better elasticity and cushioning performance, effectively absorb the vibration and shock generated during the operation of the equipment, and minimize the risk of wafer damage.
Ultra-clean and dust-free environment: Special surface treatment technology is used to ensure that the surface of the wafer gasket is smooth and dust-free, without particle pollution, and meets the strict requirements of semiconductor manufacturing for a clean environment.
“Diverse options” for wafer gaskets-customized services
Material diversification: provide a variety of material options such as silicone, fluorine rubber, polyurethane, etc. to meet different application scenarios and process needs.
Flexible customization of size and shape: Wafer gaskets of any size and shape can be customized according to customer needs, including round, square, ring, etc., which are perfectly adapted to various equipment and processes.
Clear color identification: provide transparent, black, blue and other color options to facilitate identification and management and improve production efficiency.
“Application areas” of wafer gaskets-extensive coverage
Wafer gaskets are widely used in all aspects of semiconductor manufacturing, as well as high-tech fields that require electrostatic protection and a clean environment, including:
Semiconductor manufacturing: wafer cutting, grinding, cleaning, transportation, etc.
Photoelectric display: LCD/LCM/LED panel manufacturing
Photovoltaic industry: solar cell production
Precision electronics: manufacturing of precision electronic components such as chips and laser heads
Biomedicine: pharmaceuticals, medical equipment, etc.
Aerospace: Aerospace Electronic Equipment manufacturing
Choose wafer gasket, choose quality assurance
We are committed to providing customers with high-quality, high-performance wafer gasket products and perfect customized services.All products have undergone strict quality testing to ensure that their performance indicators meet international standards and escort your production!
Contact us for exclusive solutions
If you are interested in our wafer gasket products, please feel free to contact us.Our professional team will provide you with the best quality products and solutions according to your specific needs to help your business develop efficiently!
